TY2x40 2x40kN 77kw Diesel 103hp Tension Stringing Equipment Hydraulic Tensioner

  • 1
  • 2

Brand Name : Boyu

Model Number : TY2x40

Certification : ISO9001

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 100sets/month.

Delivery Time : 15~25 days

Packaging Details : Container

Type : Tension For Overhead Stringing Machine

Engine : Cummins

Diesel : 77kw(103hp)

Cooling system : water

Max continuous pull : 2x40kN

Max intermittent pull : 2x45kN

Max speed : 5km/h

Overall dimension (length*width*height) : 4300*2250*2700mm

Contact Now

TY2x40 2x40kN Tension For Overhead Stringing Machine 77kw(103hp) Diesel



Performance

 Bull-wheel diameter  1300/1500mm
 Max conductor diameter  40mm
 Groove number  2x5
 Total weight  5800kg
 Overall dimension (length*width*height)  4300*2250*2700mm
 Max intermittent pull  2x45kN
 Max continuous pull  2x40kN
 Speed at max pull  2.5km/h
 Max speed  5km/h
 Pull at max speed  2x20kN
 Max reverse pulling force  2x35kN
 Max reverse pulling speed  5km/h
 Engine   Cummins
 Hydraulic pump  German Rexroth/Dnish Danfoss
 Main motor  German Rexroth/French Leduc
 Speed reducer  German Rexroth
 Hydraulic meter  German
 Operating handle  German Rexroth
 Diesel  77kw(103hp)
 Cooling system  water
 Electrical system  24V



Hydraulic Transmission
The machine can realize step less speed.
The machine is provided with tension presetting system.



Configuration
Hydraulic dynamometers
Hydraulic oil cooling system
Digital speed and meter counter
Hydraulic front stabilizer
Grounding connection point
Hydraulic power pack to control up to 2 separated drum stands with hydraulic motor



Additional Devices
Lighting system for the trailer
2 hydraulic rope/conductor clamp(extra charge)
Swivel guide rope roller
Trailer for towing at max speed of 30 km/h
Digital speed and meter counter



TY2x40 2x40kN 77kw Diesel 103hp Tension Stringing Equipment Hydraulic Tensioner



Other Models

Model

Max

intermittent tension

 Max continuous tension Speed at max tension Tension at max speed Max reverse pulling force Max reverse pulling speed Diesel Cooling system Electrical system
kN kN km/h kN kN km/h kw(hp)   V
TY1X7.5   7.5
TY1X20   20
TY1X20II   20
TY1X20III   20 2.5 10 15

10kw

(3600rpm)

 Air
TY1X30   30 2.5 15 20   12(16)   12
TY1X40 45 40 2.5 20 35   77(103) Water 24
TY1X50 50 40 2.5 25 45 2.4 77(103) Water 24
TY140IV 1x140 1x120 2.5 35 1x120 1.2 77(103) Water 24
TY2X35

2x40/

1x80

2x35/

1x70

 2.5

2x20/

1x40

2x30/

1x60

 5 77(103) Water 24
TY2X40

2x45/

1x90

2x40/

1x80

 2.5

2x20/

1x40

2x35/

1x70

 5 77(103) Water 24
TY2X50

2x55/

1x110

2x50/

1x100

 2.5

2x25/

1x50

2x45/

1x90

 5 77(103) Water 24
TY2X70

2x70/

1x140

2x65/

1x130

 2.5

2x25/

1x50

2x60/

1x120

 5 77(103) Water 24
TY2x70IV

2x70/

1x140

2x65/

1x130

 2.5

2x25/

1x50

2x60/

1x120

 5 77(103) Water 24
TY2X90

2x100/

1x200

2x90/

1x180

 2.5

2x40/

1x80

2x80/

1x160

 2

130kw

(2500r/min)

 Water 24
TY4x50

4x50/

2x200

4x40/

2x80

 2.5

4x20/

2x40

4x40/

2x80

 1.25 77(103) Water 24
